Beckhoff: EJ1254 – EtherCAT Plug-in Module, 4-Channel Digital Input, 24 V DC, 1 µs, Timestamping
April 13, 2021
The EJ1254 digital input module acquires the fast binary 24 V control signals from the process level and transmits them, in an electrically isolated form, to the controller. The EtherCAT plug-in module has four channels that indicate their signal state via light emitting diodes. The signals are furnished with a time stamp that identifies the time of the last edge change with a resolution of 1 ns. With this XFC technology, signal characteristics can be traced exactly in time and correlated with the distributed clocks system-wide. With this technology, machine-wide parallel hardware wiring of digital inputs or encoder signals for synchronization purposes is often no longer required.
- – suitable for particularly fast signals due to very low input delay
- – synchronized operation through distributed clocks XFC technology possible
- – support of XFC technology timestamp
