Newark 86318CY SL005 18-Conductor Shielded Cable
September 21, 2021
The 86318CY SL005 is a 18-conductor Shielded Cable with 22AWG finely stranded tinned copper conductor and lubricated semi-rigid PVC insulation. The 86318CY series multi-conductor cable comes with a slate oil-resistant PVC jacket and flex aluminum/Mylar tape shield. The Xtra-Guard® flex cable designed to provide excellent performance in high-flex, high torsion and continuous-flex applications. The rounded geometry helps insure a liquid-tight installation per IP67 or NEMA 6 rating. Supra-Shield® provides precise EMI interference resistance for your specific application is easily achievable and it meets NFPA standard 79 for industrial machinery.
115lbs Maximum pull tension
ft at 1kHz Nominal conductor to conductor capacitance
ft at 1kHz Nominal ground capacitance
ft Nominal inductance
1000ft at 20°C Nominal conductor DC resistance (DCR)
1000ft at 20°C Nominal OA shield DC resistance (DCR)
Robotics, Automation & Process Control, Industrial
