Amphenol Piher PSRC-2P: Touchless Sensing for Demanding Environments

Amphenol Piher PSRC-2P Angular Position Sensors offer touchless sensing for demanding industrial and vehicle environments. The rugged construction and advanced engineering of the sensors provide highly accurate angular measurements in harsh conditions. The magnet and sensor modules are housed separately allowing them to be placed anywhere along the pivoting shaft.

The PSRC-2P angular position sensors feature ±10V voltage protection and ±0.3% typical independent linearity in a compact low-profile package. These sensors include customizable electrical angles, multiple output options, and IP-rated protection against dust and moisture. The PSRC-2P angular position sensors are ideal for industrial automation, marine and medical devices, vehicle control systems, and home and building automation.

April 3, 2025 - Mouser_ Amphenol Piher PSRC-2P Angular Position Sensors

Features

  • True Touchless Operation: Without any internal or external gears or linkages the sensor is easily assembled and calibrated and free from wear and tear over lifetime.
  • Virtually Unlimited Mechanical Life: The separation of electronics and magnet module allows for a virtually unlimited lifetime independent of number of revolutions.
  • IP67 & IP69K Rated: Made for harsh environments with IP69K sealing, high operating temperature range as well as shock and vibration resistance allow the use in the most demanding environments.
  • Compact & Low-Profile Package: Without the need for a shaft the sensor is provided in an exceptionally compact and low-profile package that fits in space constraint applications.
  • Fully Customizable: Adaptable to your requirements with custom mechanical design, programmable transfer function and switch outputs as well as different output protocols and redundancy levels available.

Applications

Automotive

  • Gear selector
  • Transmission systems

Industrial

  • Robotic/hydraulic arm position
  • Valve monitoring
  • IoT modules
  • Vacuum circuit breaker monitoring

Off-Highway

  • Bucket position
  • Pedal/throttle position
  • Hitch position
  • Bus suspension/kneeling position
  • Transmission systems

Marine

  • Trim/tilt position

Home & Building Automation

  • HVAC damper actuator monitoring

Specifications

  • ±0.3% typical independent linearity
  • ±3mm maximum allowed radial offset
  • ±10V voltage protection
  • -40°C to 85°C operating temperature range

Supply Current:

  • 8.5mA typical single version
  • 17mA typical redundant version
  • 47mA typical CAN version

Resolution:

  • 12-bit analog
  • 16-bit from µC CAN

Output:

  • Simple
  • Redundant
  • Full-redundant

Source
