PanelSeT CRN is a multi-purpose steel wall-mounting enclosure designed for use in harsh environments. It is certified by cULus and DNV-GL and has an IK10 (IEC62262) rating and an IP66 (IEC60529) rating, making it highly resistant to dust and water. This enclosure has a nominal height, width, and depth of 800mm, 800mm, and 200mm, respectively, and is grey-coloured (RAL7035) with an epoxy-polyester powder surface finish. The PanelSeT CRN consists of a body, a plain door with a three-point lock and a 3mm double-bar insert, a mounting plate, and two cable gland plates at the bottom. The door can be opened up to 120°, allowing easy access to the equipment inside; it is possible to change the opening side of the door (reversible). The door, the cable gland plate, and the mounting plate can be removed for maintenance purposes, with the net weight of the enclosure being 33kg. This variant has sides made from a single folded section and a back welded with double profile forming a protected sealed area, with the accessibility for operation being at the front. This compact enclosure is cULus certified.
