Mouser: TE Connectivity IoT Wireless Vibration Sensors

TE Connectivity’s IoT Wireless Vibration Sensors consist of two options, the 85x1N and 89x1N series, that deliver excellent stability and longevity to industrial monitoring. The 85x1N implements Bluetooth Low Energy, while the 89x1N utilizes LoRaWAN technology, and both series fit seamlessly into tight spaces and diverse environments. The TE IoT Wireless Vibration Sensors offer a wide bandwidth, with superior resolution of up to 10kHz, compared to 4kHz in standard MEMs-based models.

The format features short and long-range reach with edge-computing for user-configurable settings and features. The 85x1N and 89x1N series were developed with harsh environments in mind, providing IP66/67 protection. The sensors are certified by ATEX, NEC, CSA, CE, and FCC. The long battery life combined with the high-stability piezoelectric core design requires minimal maintenance and supplies excellent stability over the long term. Compatible with industrial standard mounting techniques, these wireless vibration sensors can be easily installed in existing locations and machinery.

Features

  • Piezoelectric 1-axis or 3-axis accelerometer.
  • Wide bandwidth to 10kHz.
  • 2100mAh battery capacity provides up to 10 years of battery life and reduces long-term operational costs.
  • ATEX C1D1, ATEX C1D1 Zone 0, NEC Class I, Division 1, and ATEX Ex ia IIC, Groups A, B, C, and D T4, and ATEX Ex ia IIC T4 Ga certifications.
  • Embedded FFT signal analysis.
  • Lightweight, compact design weighs 200 grams with a volume of 5 cubic inches.
  • Weatherproof with IP66/67 rating.
  • Exceptional long-term stability.
  • Programmable and customer-configurable.
  • Stud, magnet, or adhesive mounting accessories.
  • Compatible with the TE SensorConnect app (iOS and Android).

Applications

  • Pumps and pumping systems.
  • Oil and gas equipment monitoring.
  • Gearboxes and turbines.
  • Conveyor systems.
  • IIoT end-to-end platforms (E2E) supporting multiple end-markets.

Specifications

  • Wireless protocol of BLE 5.0 and LoRaWAN Class A.
  • Single and three-axis accelerometer models.
  • Operating temperature of -40°C to +60°C.
  • Frequency response 2Khz to 10Khz (±3dB).
  • Non-linearity +/-1%.
  • Temperature measurement range of -40°C to +80°C.
  • Temperature measurement accuracy ±2°C.
  • Supply voltage of 3.6V.
  • Resolution at 14-bits.
  • Weatherproof (IP66/IP67).

Source

Related Articles

  • | | | | | |

    Wieland: SLC4 Series – Safety Light Curtains Type 4

    The SLC4 series from Wieland is ideal for finger and hand protection and is used to monitor safe access to machines. The SLC4 safety light curtains guarantee high availability and a reduction in machine/plant downtimes. The two different variants Base and Standard-Muting can solve standard as well as more complex applications, including muting-applications. Hazardous points of operation and access to machines must be efficiently and ergonomically monitored, especially in production processes that requires frequent intervention. SLC4 from Wieland Electric provide a highly reliable and easy to use solution for these applications.

  • Phoenix Contact: PV System Solution for Energy Self-Sufficient Systems

    Phoenix Contact is introducing a PV panel-based housing solution with several performance classes up to 190 Wp. The POS (Pico Off-grid System) includes a water- and impact-protected plastic housing, a stainless steel pole mount, and a solar panel. Computers, communication units, batteries, and more can be added to create self-sufficient solutions for field use. With the robust housing that withstands extreme weather conditions and a stainless steel pole mount, this system is a reliable and durable solution for providing energy in remote areas and demanding environments. The self-sufficient PV system uses the energy of the sun for the power supply.

  • | |

    Nexans: AC90 ISO BX Armoured Cable

    Nexans AC90 ISO-BX is a 600V armoured cable (interlocked aluminum tape) with 2 or 3 XLPE-insulated solid copper conductors (RW90) + a green XLPE-insulated copper ground (RW90) + a bare copper bond. The AC90 is for use in circuits where an isolated ground is required for minimizing the effects of harmonics and providing a low impedance path to ground. It is beneficial for special systems used for critical or sensitive equipment that need to be protected from electrical noise and interference. Reduces the risk of ground loops and common mode voltages, as ground loops which can cause errors, distortion, and damage, and common mode voltages can cause shocks, fires and interference. The AC90 helps improve performance and reliability of sensitive equipment and circuits; It also increases the accuracy, quality, lifespan, and safety of sensitive equipment and circuits. The AC90 provides a cost-effective alternative to installations in conduit.

  • Phoenix Contact: CONTACTRON CSS 0.55-3/3-EMC – Speed Starter

    In the field of machine building, you can control motors flexibly and efficiently with the CONTACTRON Speed Starter. Phoenix Contact’s mission is to work with the customer to find a suitable solution for simple motor control. The CONTACTRON Speed Starter has soft start and configurable speed for starting and reversing motors up to 480 V AC and 0.55 kW, configurable motor protection, analog input, STO function up to SIL 3/PL e, three-phase load input, with integrated EMC filter. Frequency converters are often used in applications that involve running at a variable speed or where motor ramp up and ramp down must be controlled, for example. The CONTACTRON Speed Starter combines the advantages of a compact motor starter with the essential features of a frequency converter for a wide range of applications:

  • | |

    Hannover Messe 2025: Partner Country Canada

    Canada is leading the way toward a brighter future. With expertise in fields like artificial intelligence, quantum, electric vehicles, advanced materials, clean energy, automation and robotics, Canadians are developing solutions that will shape a more sustainable world. Advanced manufacturing capabilities and world-leading research compliment Canada’s traditional strengths in natural resources. As the exclusive partner country for Hannover Messe, Canada is showcasing 220 of its brightest companies and research organizations in automation, digital transformation, alternative energy, hydrogen, and green technologies. See how Canada is shaping the future.

Changing Scene

Sponsored Content
The Easy Way to the Industrial IoT

The way to the Industrial IoT does not have to be complicated. Whether access to valuable data is required or new, data-driven services are to be generated, Weidmuller enables its customers to go from data to value the easy way. Weidmuller’s comprehensive and cutting-edge IIoT portfolio applies to greenfield and brownfield applications. Weidmuller offers components and solutions from data acquisition, data pre-processing, data communication and data analysis.

Visit Weidmuller’s Industrial IoT Portfolio.

ADVANCED Motion Controls Takes Servo Drives to New Heights (and Depths) with FlexPro Extended Environment Product Line

Advanced Motion Controls is proud to announce the addition of six new CANopen servo drives with Extended Environment capabilities to their FlexPro line. These new drives join AMC’s existing EtherCAT Extended Environment FlexPro drives, making the FlexPro line the go-to solution for motion control applications in harsh environments.

Many motion control applications take place in conditions that are less than ideal, such as extreme temperatures, high and low pressures, shocks and vibrations, and contamination. Electronics, including servo drives, can malfunction or sustain permanent damage in these conditions.

Read More

Service Wire Co. Announces New Titles for Key Executives

Bruce Kesler and Mark Gatewood have been given new titles and responsibilities for Service Wire Co.

Bruce Kesler has assumed the role of Senior Director – Business Development. Bruce will be responsible for Service Wire’s largest strategic accounts and our growing Strategic Accounts Team.

Mark Gatewood has been promoted to the role of Vice President – Sales & Marketing. In this role, Gatewood will lead the efforts of Service Wire Company’s entire sales and marketing organization in all market verticals.

Read More

Tri-Mach Announces the Purchase of an Additional 45,000 sq ft. Facility

Tri-Mach Elmira Facility

Recently, Tri-Mach Inc. was thrilled to announce the addition of a new 45,000 sq ft. facility. Located at 285 Union St., Elmira, ON, this facility expands Tri-Mach’s capabilities, allowing them to better serve the growing needs of their customers.

Positioning for growth, this additional facility will allow Tri-Mach to continue taking on large-scale projects, enhance product performance testing, and provide equipment storage for their customers. The building will also be the new home to their Skilled Trades Centre of Excellence.

Read More

JMP Parent Company, CONVERGIX Acquires AGR Automation, Expanding Global Reach

Convergix Automation Solutions has completed the acquisition of AGR Automation (“AGR”), a UK-based provider of custom, high-performance automation design and systems integration primarily to the life sciences industry.

Following Convergix’s acquisitions of JMP Solutions in August 2021 and Classic Design in February 2022, AGR marks the third investment in Crestview’s strategy to build Convergix into a diversified automation solutions provider targeting the global $500+ billion market, with a particular focus on the $70 billion global systems integration and connectivity segments. Financial terms of the transaction were not disclosed.

Read More

Latest Articles

  • Hammond: Why Are More Organizations Standardizing on Wall-Mount Server Cabinets?

    Hammond: Why Are More Organizations Standardizing on Wall-Mount Server Cabinets?
