IMO Panel Product Range: Discover the Dynamic Solutions
IMO’s Panel product range continues to deliver innovation and efficiency worldwide and is where technology and expertise in engineering come together. IMO’s Panel range has been specifically designed to meet the demanding needs of today’s panel builders and engineers whose requirements can range from a simple DIN rail terminal through to a complete panel solution.
IMO’s products allow panel builders globally to deliver significant advances through greater efficiency, reliability and high performance, thereby increasing their competitive advantage and delivering the optimum panel solution. When purchasing from IMO you can be confident that over 40 years’ experience servicing the Panel Builder market has gone into the design and development of the IMO range.
IMO Value Added Assembly Division Will Help You:
- Reduce your stock level
- Reduce cost
- Ensure quality
- Increase productivity
IMO through its Assembly Division can provide Value Added Assembly solutions built to customer specification whether you are looking for prototypes, one-off projects, or small to large volume requirements with regular deliveries, IMO can offer you a solution. As a globally recognized manufacturer of electrical components, IMO have a wide range of connection, power, control and interface products readily available from stock and are always looking forward to the next challenge. Challenge IMO and tell them about your assembly needs and see what solution they can propose. To save time and money contact IMO today with your drawings, photos and specifications.
Miniature Circuit Breakers
The IMO range of Miniature Circuit Breakers has been designed for protection of electrical installations against overload and short circuits.
- B4 4.5kA Miniature Circuit Breakers
- BR6 6kA Miniature Circuit Breakers
- B10 10kA Miniature Circuit Breakers
- B6CR 6kA Residual Circuit Breakers with Overload
- B10R 10kA Residual Current Circuit Breakers
- BIS Isolating Switches
DIN Rail Terminals
IMO’s range of DIN Rail Terminals offers the customer a host of features and benefits. With high quality throughout the IMO range includes standard modular feed-through terminals, double and triple level terminals, fused terminals, disconnects and three-level sensor terminals just to highlight a few.
IMO DIN Rail Terminals can be offered with screw clamp, push-fit or out latest innovation – Spring Clamp Pluggable connections and although offered in beige as standard, the range is available in multiple colours throughout, allowing OEMs and installers to use colour code systems within their panels. In line with the constant drive towards greater packing density of all components within the control panel, IMO has made its DIN Rail Terminals both lighter and more compact whilst their strength is ensured by using self-extinguishing unbreakable polyamide 6.6.
IMO DIN Rail Terminals are offered in sizes from 2.5mm2 through to 240mm2 and have bevelled cable entry to simplify the introduction of the conductors. IMO terminals are designed to meet both national and international standards, and have gained approvals from organisations such as CSA, UL, DNV, VDE and a number of products are also certified to IECEx
Power Supplies
IMOs range of industrial Power Supplies have all been designed especially for the control and automation marketplace. Offering the benefits of universal input, and the security of IMOs 3-year warranty, the three ranges of PSU provide multiple choices for low power electrical or electronic systems commonly used in automation applications.
All IMO Power Supplies are cUL approved and offer high efficiency, making them an exceptionally reliable power source for components such as sensors, relays, contactors, timers, temperature controllers, PLCs, process controllers and HMIs, all of which are available from IMO.
- Single & Three Phase Versions
- Universal Input
- AC/DC Operation
- High Efficiency up to 92%
- Class 2 Types
- From 10W to 960W
- Plastic & Metal Housing
- Short Circuit Protection
- DIN Rail Mountable
AC Isolators
IMO offers a comprehensive range of high-quality AC Isolators with switching capabilities ranging from 20A to 125A, both in 3 and 4 Poles. Within the range, there are a number of different mounting types including Panel Mount, DIN Rail Mount and Enclosed, plus there are a range of handles and extendable shafts to suit most applications, as well as other accessories to compliment the range.
DC Isolators
Solar Isolators “SI..” switchgear for interrupting the solar panels from the DC/AC Inverter. Photovoltaic installations have to be equipped with DC-isolators in accordance with IEC 60364-7-712.
- TRUE DC Isolator to UL508i
- Available in 2,4,6,8 Pole Versions
- Max. Rated Current 58A @ 1000VDC (Acc. To DC21B for SI32)
- Max. Rated Current 80A @ 600VDC (Acc. To DC21B for SI55)
- High Reliability Self-Cleaning & Vibration Resistant Knife Contacts
- Arc Suppression Chamber
- Operator Independent High-Speed Switching (Typically 3ms)
- Additional Security with Patented “Safelock” Function
- Compact & Space Saving Design
- Maximum Operator Torque of 1Nm for Easy Operation (SI16-32)
- Poles can be Wired in Series to Increase Rating (DC21B & DC22B)
- Large Box Terminals with up to 25mm2 Cross Sectional Wiring Area
- Different Mounting Versions Available (DIN / Base / Panel)
- Solar Connectors are Available (Plug / Socket / Branch)
Contactors 4 – 400kW
- 10A up to 1200A 400V AC3
- Minimum Size & Maximum Performance
- AC & DC Operated
- Ambient Temperature -40°C to +90°C (T90)
- DIN Rail Mounting up to 115A AC3
- Bifurcated Aux. Contacts
- High Contact Reliability
- 4 Pole Full Rated Version Available
- Coil Connection Top & Bottom (MC10N to MC22N)
Modular Heating & Lighting Contactors
- Suitable for Control of Lamps, Heating, Air-Conditioning & Motor Control
- 2 or 4 Pole Version
- 20A up to 63A 400V AC1
- Multiple Pole Configuration Available
- Space Saving Design
- Low Switching Noise
- Low Power Consumption
- Coil Voltage 230VAC or 24VAC
- Hum-Free Versions Available with AC/DC Coil
Motor Protection Circuit Breakers C4
IMO C4 Motor Protection Circuit Breakers are designed to be a compact reliable unit that offers high protection for 3 phase induction motors but can also be used as a motor starter, and for line protection. Integrating the functions of a circuit breaker and thermal overload relay in single unit so they significantly reduce the space requirements and wiring necessary for an installation that would have traditionally used a three-component starter assembly.
With ratings from 0.16A to 100A in 3 frame sizes the IMO C4 has a short circuit breaking capacity of 100kA (Icu) and incorporates both thermal overload functionality and phase failure protection for phase-to-phase faults thereby offering comprehensive protection of the motor and controlling electrical circuitry. The C4 is available with either rocker or rotary control and is complemented with a wide range of accessories that enable it to be connected to supplementary products, such as an IMO contactor, to give greater versatility.
The design flexibility of the C4 ensures its convenience for installers, with the availability of auxiliary contacts that can be front or side mounted, to busbar systems available for the interconnection of up to 5 units; the C4 can be wired from either the top or bottom supply terminals without any reduction in ratings. DIN rail and panel mount models are designed in accordance with IEC 60947-1, IEC 60947-2, IEC 60947-4-1, VDE 660 and cUL approved (E223201) ensure that the IMO C4 circuit breakers are ideal for installation and OEM applications.
- Motor Protection Rating up to 100 Amps
- Short Circuit Breaking Capacity up to 100kA
- Phase Failure Protection
- DIN Rail Mounting
- Wide Range of Accessories
Industrial Power Relays & Sockets
IMO’s range of Relays include Signal Relays, Power Relays, Automotive Relays and Solar Relays, and range of compatible sockets. IMO’s relay manufacturing goes back as far as 1970, and over the years they have strived to innovate and produce new types of relays for developing technologies. In 1984 IMO developed the first BT Type 47 Telecom Relay, and again in 1990 they launched the first BABT compliant isolation relay for data transfer, confirming their place as a major global relay manufacturer.
As part of their innovative nature, they have manufactured a range of Slimline DIN Rail Mount Relays at just 6mm wide, which provide substantial space savings in a panel when compared to traditional plug-in style relays. The range with plug-in relays rated at 6 Amps allows easy maintenance without the need for complete rewiring of the socket. The sockets are available in wide operating voltages for both AC and DC circuits within the same unit, providing greater flexibility for the user and reducing the number of stock items required.
Cam Switches
IMO’s range of Cam Switches incorporates a unique building block system that allows for any number of switch variants to be built and supplied to the customer. Such is the flexibility of the Cam Switches, that they can be utilised in countless applications including mains/motor switching and control and instrumentation circuits. The standard contact rating is 20A, although higher ratings are available on request and these switches have double interruption per pole and two contacts per cell and standard units incorporate a 22.5mm central fixing for panel mounting.
The switch body and actuators are supplied separately to provide a choice of four different set up configurations. Connection from actuator to switch body is made through a solid aluminium shaft. Manufactured in accordance with IEC 60947-3, the new Cam Switches carry an IP65 rating appropriately when mounted in a suitably rated enclosure and have ‘finger proof’ screw terminals. The switch body is supplied complete with legend plate and all units are cUL/UL approved.
Enclosed Starters
- Pushbutton Stop/Start
- IP65 ABS Enclosure
- Prewired to Accept Overload (U12/16E..)
Fluid Level Detection
IMO’s WLC2-230AC is a microprocessor based, multifunction Liquid Level Controller designed specifically to provide monitoring and control of liquids with a wide sensitivity range, such as saltwater, chemicals etc. The WLC2-230AC also has the ability to detect liquid leaks, provide protection of pumps against dry running, and even control of mixing ratios of various liquids. The WLC2-230AC is capable of using up to 6 probes simultaneously.
Ø22.0mm Push Buttons & Pilot Lights
- IP67/IP65 Protection
- Opaque or Illuminated
- Aluminiun, Black or Chrome Bezel
- Snap-On Contact Blocks
- Colour Coded Contacts
- International Approvals Including cUL Approved Products
- Maintained or Spring Return
- Assembled Control Stations
- 1/2/3 Hole Push Button Enclosure
- Key Operated Switch
- Labelling Accessories
Timers
IMO’s comprehensive range of DIN Rail mountable Timers delivers up-to-the-minute technology. Ranging from the simple single function through to the multi-function timer with display, these timers are being used daily in all types of applications and industries. The ultra compact design and top-mounted terminals make installation easy, even in the tightest of panels, providing customers with a solution at minimal cost. Wide input voltage capability allows these products to be installed in applications across the world.
IMO’s range of Panel Mount / Plug-In Timers provide users with a range of settings and functionality and timing ranges between 0.1sec and 100hrs. Other key features include indication of time range, time up and power on timing. IMO Sockets are available to complement the panel mounting facility thereby giving the installer the option of DIN rail mounting, surface mounting or printed-circuit board mounting.
IMO Timers are always high quality and are backed with a Three-Year Warranty. If you require a timer that is not listed, please contact IMO to receive information on the full range.
- 17.5mm DIN Rail Mount Range
- 48 DIN Panel Mount Range
- Multifunction
- On / Off / True Off Delay
- Asymmetrical
- Star Delta
- 24 -240VAC/DC, 400VAC (TDSD1)
- Wide Input Voltage Range
